Precision synchronizer og master clock til audio post production.
Hold dit Pro Tools system og tilsluttede enheder i perfekt sync, uanset kompleksiteten af dit setup. Pro Tools Sync X er rygraden i det moderne audio post production studie med pålidelig low-jitter clocking og nær sampleakkurat lås med frame edge alignment. Sync X er uundværlig til dubbing, ADR, Foley og andre krævende workflows og et must-have i ethvert studie, der abejder med audio sync til billede.
SYSTEM REQUIREMENTS
Avid-qualified macOS or Windows computer
Pro Tools | HDX eller HD Native system
SAMPLE RATES
44.1, 48, 88.2, 96, 176.4, and 192 kHz
VIDEO REFERENCE
Video Reference I/O
1 x BNC input
2 x BNC outputs
Video Reference Generator
4 x BNC outputs
Video Reference Format Support
Sync X supports the following HD/SD formats when using the internal or an external video reference generator, with automatic format detection:
NTSC
PAL
Slow PAL – 23.976
Slow PAL – 24
720p – 23.976
720p – 24
720p – 25
720p – 29.97
720p – 30
720p – 50
720p – 59.94
720p – 60
1080i – 47.95/1080psf – 23.976
1080i – 48/1080psf – 24
1080i – 50/1080psf – 25
1080i – 59.94/1080psf – 29.97
1080i – 60/1080psf – 30
1080p – 23.976
1080p – 24
1080p – 25
1080p – 29.97
1080p – 30
1080p – 50*
1080p – 59.94*
1080p – 60*
* Format not supported for internal video reference generation.
CLOCK REFERENCE AND VIDEO / AUDIO TIMECODE POSITIONAL REFERENCE
Word Clock I/O
1 x BNC input
6 x BNC outputs
10 MHz/AES3id Input
1 x BNC
AES3id Output
1 x BNC
AES3 I/O
1 x DB25 port
Loop Sync I/O
1 x BNC input
1 x BNC output
Video Reference I/O
1 x BNC input
2 x BNC outputs
LTC I/O
1 x XLRF input
1 x XLRM output
GPIO, Bi-Phase / Tach, Pilot
1 x DB25 port (specific cables required for different applications)
MIDI Output
1 x DB9 port
MEASUREMENTS
Average Long-Term Jitter
72 ps
Measured at 1 ms interval as specified in AES-12id-2020. Jitter will vary slightly based on sample rate and video reference format.
Clock Accuracy
± 1 ppm
Drift with Temperature Variation
± 1 ppm over -4º–158º F (-20º ~ 70º C)
ADDITIONAL SPECIFICATIONS
Host Connection
1 x DigiSerial Port (Mini DIN 8-pin)
Machine Control
1 x DB9 port
Front Panel Display
2 OLEDs (256 x 64) to display reference info, audio sample rate, timecode, and other details
Navigational buttons (6)
ID button (to easily identify the unit in a rack)
Status LEDs (3)
Inkluderet:
Pro Tools | Sync X interface
Power cable
Serial cable
BNC cables (2)
MIDI breakout cable
Rackmount screws and desktop feet
Registration card
Documentation (Warranty card, Health & Safety Guide, Regulatory & Safety Sheet)
