Blackmagic DeckLink 4K Extreme 12G – Professional 12G-SDI 4K Capture & Playback Card
The Blackmagic DeckLink 4K Extreme 12G is a premium PCIe video capture and playback card, engineered for the most demanding broadcast, post-production, and high-end film workflows. Featuring advanced dual 12G-SDI connections and HDMI 2.0 input/output, it supports the latest Ultra HD and DCI 4K formats at up to 60 frames per second with deep color fidelity.
Designed for professionals working in HDR, stereoscopic 3D, and 4K/8K finishing, the card offers high-quality 10-bit and 12-bit RGB and YUV video, along with support for Rec. 2020 and HDR metadata. With dual-channel fill and key output, analog video I/O, AES/EBU audio, RS-422 deck control, and full compatibility with leading software like DaVinci Resolve, Adobe Premiere Pro, Avid, and Final Cut Pro, the DeckLink 4K Extreme 12G is an all-in-one solution for high-performance video workflows.
Whether you are working in a color grading suite, a live production rack, or a high-end editing station, this card delivers flawless picture quality, speed, and professional connectivity to handle everything from SD to DCI 4K and beyond.
Key Features:
- Dual 12G-SDI inputs and outputs for high-bandwidth 4K/Ultra HD workflows
- HDMI 2.0 input and output for consumer and professional displays
- Real-time 4K DCI and Ultra HD capture and playback at up to 60 fps
- Supports 10-bit YUV and 12-bit RGB 4:4:4 color formats
- HDR support including HDR10 and HLG metadata
- Stereoscopic 3D support and dual-channel fill and key output
- Analog video in/out, AES/EBU audio, and RS-422 deck control
- Compatible with macOS, Windows, and Linux
Technical Specifications:
- Video Inputs: 2 x 12G-SDI, 1 x HDMI 2.0, 1 x analog video
- Video Outputs: 2 x 12G-SDI, 1 x HDMI 2.0, 1 x analog video
- Audio I/O: 2-channel AES/EBU, 2-channel balanced analog audio
- Supported Resolutions: Up to 4096 x 2160p60
- Colour Space: 10-bit YUV, 12-bit RGB
- HDR Support: HDR10, HLG, Rec.2020
- Interface: PCI Express Gen 3 x8
- Deck Control: RS-422
- Operating Systems: macOS, Windows, Linux
Ideal For:
The DeckLink 4K Extreme 12G is ideal for film post-production, color grading, live UHD broadcasting, VFX, and high-resolution video finishing. With its extensive format support and robust connectivity, it provides a professional-grade solution for today’s 4K and HDR production demands.
Push the limits of quality and performance with the Blackmagic DeckLink 4K Extreme 12G.
