Neumann BCM 104 (Condenser Microphone)
The Neumann BCM 104 is a broadcast-grade large-diaphragm condenser microphone designed for radio, podcast, and voiceover professionals who demand uncompromising sound quality Combining Neumann’s legendary precision with a rugged broadcast-oriented design, the BCM 104 delivers warm, natural, and detailed vocal reproduction ideal for on-air and studio environments
Its fixed cardioid polar pattern ensures excellent isolation from room noise and other sound sources, while the integrated pop screen and internal shock mount minimize plosives and handling noise With transformerless circuitry and extremely low self-noise, the BCM 104 provides a clean, transparent signal path that captures every nuance of the voice
Features
- Large-diaphragm condenser microphone for broadcast and studio use
- Cardioid polar pattern for focused sound capture and noise rejection
- Integrated pop filter for plosive control during close speech
- Internal shock mounting for reduced handling and structure-borne noise
- Transformerless output stage for pristine signal integrity
- Low self-noise and wide dynamic range
- Detachable head grille for easy cleaning
- Handcrafted in Germany to Neumann’s exacting standards
Applications
- Broadcast and radio production
- Podcast and voiceover recording
- Streaming and post-production
- Studio vocals and narration
Included
- Neumann BCM 104 microphone
- Integrated XLR swivel mount
- Protective foam windscreen
Technical Specifications
- Acoustic Principle: Pressure gradient condenser
- Polar Pattern: Cardioid
- Frequency Response: 20 Hz – 20 kHz
- Sensitivity: 22 mV/Pa
- Equivalent Noise Level: 7 dB-A
- Maximum SPL: 138 dB (05% THD)
- Signal-to-Noise Ratio: 87 dB (A-weighted)
- Output Impedance: 50 Ω
- Power Supply: 48V ±4V phantom power
- Connector: XLR 3-pin (integrated swivel mount)
- Dimensions: 64 × 85 mm (⌀ × L)
- Weight: approx 500 g
