Neumann U 47 FET
The Neumann U 47 FET is a reissue of the legendary solid-state version of the iconic U 47 microphone Originally introduced in 1972, the U 47 FET quickly became a studio classic for its powerful sound, high SPL capability, and unmistakable Neumann tone It is renowned for capturing vocals, kick drums, bass cabinets, and brass instruments with exceptional authority, detail, and warmth
Equipped with the same K 47 large-diaphragm capsule found in the original tube U 47, the U 47 FET combines a classic sonic signature with the reliability of modern solid-state electronics Its robust build, smooth frequency response, and high headroom make it one of the most versatile and characterful microphones available for professional studios
Features
- Large-diaphragm condenser microphone with classic U 47 capsule (K 47)
- Solid-state FET circuitry for high SPL handling and consistent performance
- Cardioid polar pattern with extended low-end response
- Switchable –10 dB pad and low-cut filter
- Maximum SPL of 137 dB (147 dB with pad engaged)
- Full, rich tone ideal for vocals, kick drum, and bass instruments
- Transformer-balanced output for musical harmonic character
- Handcrafted in Germany using premium components
Applications
- Lead and backing vocals
- Kick drum and bass cabinets
- Brass and wind instruments
- Guitar amplifiers and percussion
- Voiceover and broadcast
Included
- Neumann U 47 FET microphone
- Wooden presentation box
- EA 87 elastic shock mount (optional in set configurations)
Technical Specifications
- Acoustic Principle: Pressure gradient condenser
- Polar Pattern: Cardioid
- Frequency Response: 40 Hz – 16 kHz
- Sensitivity: 8 mV/Pa
- Equivalent Noise Level: 18 dB-A
- Maximum SPL: 137 dB (147 dB with –10 dB pad)
- Output Impedance: 150 Ω
- Low-Cut Filter: Switchable (100 Hz, –6 dB)
- Power Supply: 48V ±4V phantom power
- Connector: XLR 3-pin
- Dimensions: 160 × 65 × 65 mm
- Weight: approx 710 g
