Moog Minimoog Model D – Mahogany Cabinet

Overview

• MIN-MOOG-D-05 – Mahogany cabinet
• Extremely limited final production run
• Single incoming stock delivery (late April / early May)
• Hand-built by the Moog Music team in North Carolina, USA

Description

Originally released in 1970, the Minimoog Model D was the world’s first portable synthesizer and became the archetype for all electronic keyboards that followed. It combined the massive sound of Moog modular systems with a pre-wired, performance-ready design.

The instrument was embraced by artists such as Herbie Hancock, Kraftwerk, Rick Wakeman, Sun Ra, Giorgio Moroder, Bernie Worrell, and Gary Numan — shaping entire genres of music.

This three-oscillator, monophonic analog synthesizer is housed in a handcrafted Appalachian cherry cabinet with a hand-finished aluminum chassis. Its legendary ladder filter, oscillators, and mixer retain the exact component layout of the original.

While the sound engine remains untouched, modern enhancements include a dedicated analog LFO, Fatar keybed with velocity and aftertouch via CV, MIDI integration, mixer feedback for overdrive, and a spring-loaded pitch wheel for improved playability.

Specifications

Keyboard

• Number of Keys: 44
• Range: F0 to C4
• Action: Synthesizer (Spring)
• Note Priority: Low, High, Last (Selectable)

Sound Engine

• 3x Oscillators, Noise Generator, External Audio Input
• Frequency Range: 0.1 Hz to 20 kHz
• Oscillator Stability: > 0.25%
• Waveforms: Triangle, Sawtooth, Pulse, Reverse Saw
• Noise: White & Pink

Filter & Modulation

• Filter Type: Ladder Low Pass
• Frequency Range: 10 Hz to 20 kHz
• Slope: 24 dB/Octave
• LFO: 0.05 Hz to 200 Hz (Triangle / Square)
• Filter Tracking: ⅓, ⅔, 1:1

Connectivity

• MIDI In / Out / Thru (5-pin DIN)
• CV Outputs: Pitch, Gate, Velocity, Aftertouch
• Audio Outputs: High, Low, Headphones
• External Modulation Input: +10 mV to +2 V

General

• Power: 100–240V, <12W
• Weight: 14.5 kg / 32 lbs
• Dimensions: 727 x 435 x 146 mm
• Glide Rate: 1 ms to 10 s
• Pitch Bend Range: ±7 semitones

In the Box

• Minimoog Model D Analog Synthesizer
• Power Supply
• User Manual
• Poster Newspaper
