Tro mod sin inspiration er WA-2A en all tube kompressor. WA-2A er også udstyret custom Cinemag input og output transformere, fire premium vakuumrør, og den legendariske Kenetek opto-celle, der af mange anses for at være verdens fineste.
Specifikationer
- 2A Style, Transformer balanced, high voltage, opto (Light controlled) tube compressor
- Fully discrete signal path
- Utilizes custom USA made CineMag input and output transformers
- Utilizes USA made Kenetek opto attenuator. Socketed to allow for retro-fitting with other opto-cells
- Premium Tung-Sol and Electro-Harmonix tubes. 2x 12ax7, 1x 12bh7, 1x 6aq5 (or 6p1 – interchangeable)
- Variable Pre-emphasis, allows for compression hipass filtering
- Stereo-link capability
- XLR and TRS balanced line level inputs – 600 ohms impedance
- XLR and TRS balanced line level outputs – 600 ohms impedance
- Frequency Response +/- 1 dB, 15 Hz to 20kHz
- Gain 40 dB ±1dB
- Input Level +16 dB maximum
- Output Level +10 dB nominal, +16 dB maximum
- Distortion Less than 0.1% THD at ±10 dBm
- Noise = -74dB
- Attack Time – 10 milliseconds
- Release Time – 0.06 seconds for 50% release; 0.5 to 5 seconds for complete release
- Meter shows both dB gain reduction and dB output
- Power – 115/230 volts (switchable), 50/60 Hz
- Dimensions – 19″ Rackmount chassis, 2U. 19″ x 7″ x 3.5″
- Weight – 12 lbs
