Warm Audio WA76 Discrete Compressor

4.777,00 kr. (3.821,60 kr. ex. moms)

Ikke på lager - kan bestilles

FORVENTET LEVERING: 15 nov 2024
(ved bestilling idag!)

Varenummer (SKU): 23983 Kategorier: ,
Brand:Warm Audio

Kompressor i den klassiske 1176 stil, som kan reproducere “all buttons in”-indstillingen fra den originale 1176.

  • True to the Classic 1176 compressor in design and performance
  • Completely discrete signal path
  • Modeled after the D revision
  • Utilizes USA made CINEMAG input and output transformers
  • Supports the famous “all buttons in” ratio setting
  • Ultra fast attack time
  • Class A line level output amplifier
  • Input impedance – 600 ohms, bridges-T control (floating)
  • Frequency Response ± 1 dB 20 Hz to 20kHz
  • XLR and TRS inputs. XLR and TRS outputs
  • 50db of gain
  • Less than 0.4% total harmonic distortion from 50 Hz to 20 kHz with limiting
  • Signal to noise ratio is greater than 74 dB at +25 dBm
  • EIN -104.1 dbm
  • Attack time, 20 microseconds to 800 microseconds
  • Release time, 50 milliseconds to 1 second
  • Meter provides dB gain reduction and dB output
  • Internal power supply, external 24v AC power transformer
  • 19″ Rackmount chassis, 2U
  • 1-year warranty
