Heritage Audio 8-Slot 500 Series OST Enclosure with ADAT Out
The Heritage Audio 8-Slot 500 Series OST Enclosure with ADAT Out revolutionizes the 500 series format by seamlessly combining Heritage Audio’s trusted On Slot Technology (OST) with modern digital connectivity. Designed for professional studios and mobile rigs, this enclosure allows up to eight 500 series modules to be directly routed into your DAW via an integrated high-end 24-bit/192 kHz ADAT output, offering pristine digital conversion without the need for external interfaces.
Each slot is individually regulated using Heritage Audio’s OST, ensuring clean, stable, and isolated power for optimal module performance. The built-in ADAT output makes it incredibly easy to integrate your favorite analog modules into today’s digital workflows — perfect for engineers who demand both analog warmth and digital precision.
Featuring balanced analog outputs, XLR and TRS connectivity, and a rugged metal chassis, this 8-slot enclosure delivers flexibility, portability, and the highest audio quality. Whether you are recording, mixing, or building a mobile setup, the Heritage Audio 8-Slot OST Enclosure with ADAT Out is the ultimate modern modular solution.
Key Features:
- 8-slot 500 series enclosure with integrated 24-bit/192 kHz ADAT output
- Heritage Audio’s On Slot Technology (OST) for individual slot power regulation and protection
- Directly connect your 500 series modules to any ADAT-compatible DAW or audio interface
- High-end AD/DA converters for premium digital audio quality
- Balanced XLR and TRS analog outputs per slot
- External high-quality PSU for quiet, stable operation
- Compatible with all standard 500 series modules, including high-current designs
- Heavy-duty metal construction for professional reliability
- Ideal for hybrid analog-digital studio setups, mobile recording rigs, and modular system expansions
Technical Specifications:
- Slots: 8 (500 series standard)
- Input/Output: Balanced XLR and TRS per slot, optical ADAT out
- ADAT Output: 8 channels at 48 kHz, 4 channels at 96 kHz, 2 channels at 192 kHz (S/MUX protocol)
- AD/DA Conversion: 24-bit resolution, up to 192 kHz sample rate
- Power Supply: External PSU included (100–240V AC, 50/60Hz)
- Power Output per Slot: ±16V and +48V phantom power, individually regulated
- Maximum Current: 400mA per rail per slot
- Dimensions: Standard 19″ rackmount (3U)
- Weight: Approximately 6.5 kg
Bridge the gap between analog warmth and digital precision with the Heritage Audio 8-Slot 500 Series OST Enclosure with ADAT Out — the smartest way to integrate 500 series gear into modern recording workflows.
