PreSonus HP60 – 6-Channel Headphone Amplifier System
The PreSonus HP60 is a professional 6-channel headphone amplifier system designed for studios, broadcast facilities, and live performance setups.
It provides individual control for each performer, allowing musicians and engineers to customize their own headphone mixes for optimal comfort and performance.
With flexible inputs, high output power, and a rugged 1U rackmount design, the HP60 delivers clean, dynamic, and distortion-free monitoring in any studio environment.
Key Features
- 6 independent headphone amplifier channels, each with dedicated level and mix controls.
- Individual “More Me” mix control on each channel for fine-tuning between two stereo sources.
- 2 stereo main inputs (A and B) allow for flexible routing and simultaneous monitoring setups.
- External input per channel for adding click tracks or personalized signals to each mix.
- High-power headphone outputs capable of driving a wide range of headphones efficiently.
- Direct stereo line outputs on each channel for sending mixes to external monitors or recorders.
- 1U rackmount metal chassis designed for professional studio or live rig installation.
- Ultra-low noise and distortion ensure clean, transparent sound reproduction.
- Flexible daisy-chain capability for expanding larger monitoring systems.
- Ideal for tracking, rehearsals, and live performance monitoring.
Applications
- Recording Studios: Provide multiple performers with independent monitor mixes during sessions.
- Broadcast and Podcast Production: Deliver separate headphone feeds to hosts and guests.
- Live Sound and Rehearsal Rooms: Offer consistent, high-quality headphone monitoring for bands and crews.
- Education and Training Facilities: Perfect for classrooms or music labs requiring multiple headphone outputs.
Technical Specifications
| Number of Channels | 6 independent stereo headphone amplifiers |
|---|---|
| Main Inputs | 2 × stereo TRS (Input A and Input B) |
| External Inputs | 6 × stereo TRS (one per channel) |
| Line Outputs | 6 × stereo TRS (one per channel) |
| Headphone Outputs | 6 × 1/4” TRS stereo jacks |
| Frequency Response | 10 Hz – 50 kHz ±0.5 dB |
| THD+N | < 0.002% @ 1 kHz, +4 dBu |
| Output Power | 150 mW per channel @ 60 Ω |
| Signal-to-Noise Ratio | > 98 dB |
| Input Impedance | 10 kΩ balanced |
| Power Supply | Internal 230V / 115V AC, 50/60 Hz |
| Rackmount Size | 1U (standard 19” rack width) |
| Dimensions (H × W × D) | 44 × 482 × 171 mm |
| Weight | 2.6 kg |
| Construction | All-metal chassis for long-term durability |
Why Choose the PreSonus HP60?
The PreSonus HP60 delivers the power, flexibility, and clarity needed for any multi-user headphone setup.
Its dual input design and per-channel “More Me” controls make it easy for performers to hear exactly what they need during sessions.
Whether you’re recording a full band, running a broadcast studio, or managing multiple performers on stage, the HP60 provides unmatched control, power, and audio transparency in a compact, professional form factor.
