Oberheim TEO-5

Unparalleled analog richness
At the heart of the TEO-5 lies its pure analog signal path, featuring genuine VCOs and VCFs that capture the quintessential Oberheim warmth and power. Each voice boasts selectable waveshapes — triangle, sawtooth, and variable pulse — providing a rich palette for creating unique sound textures. Coupled with analog through-zero FM synthesis, the TEO-5 allows for the creation of new sonic textures previously unachievable in older Oberheim models.

Sculpt your sound with the Legendary SEM Filter
The classic SEM filter in the TEO-5 is a central feature, enabling artists to shape their sounds with precision. This versatile filter transitions seamlessly from low-pass to high-pass, with a notch filter setting in between, controlled by a simple state knob. This flexibility is vital for both live performances and studio sessions, offering musicians the ability to adapt and tweak their sound on the fly.

Expansive sound design capabilities
TEO-5’s 64-step polyphonic sequencer and multimode arpeggiator are gateways to endless creative expansions. Whether you’re composing complex sequences or need rhythmic accompaniment, these tools are designed to enhance musical expression. The sequencer invites intricate melodic construction, while the arpeggiator keeps the rhythm engaging and diverse, suitable for any musical genre.

Performance-ready controls and effects
The Oberheim TEO-5 is equipped with a premium semi-weighted Fatar keyboard, known for its expressiveness and sensitivity to touch, making every performance a nuanced experience. Adding further to its performance arsenal are the dedicated digital effects, including reverb, multiple delay types, and legendary modulators. These effects not only enrich the sound but also bring Oberheim’s storied sonic history into the modern age, perfect for both stage and studio work.

Features
5-voice polysynth with VCO/VCF, including 2 VCOs and a sub-oscillator per voice
Each oscillator offers selectable waveshapes: triangle, saw, and variable pulse
Oscillator synchronization and through-zero FM modulation via dedicated controls
Switchable key tracking and a white noise generator for each oscillator
Classic SEM state variable filter with modes ranging from low-pass through notch to high-pass
Filter includes bi-polar envelope amount, velocity modulation, and keyboard tracking
DADSR envelope generators for filter and amplifier, both with velocity modulation and assignable modulation destinations
Two low frequency oscillators (LFOs) featuring five wave shapes and tempo synchronization
Vintage knob to simulate variations in component behaviour, mimicking vintage synths
Channel aftertouch with bi-polar amount and assignable destinations
Master clock includes tap tempo, BPM control/display, and MIDI sync
Arpeggiator with multiple modes and range settings
Polyphonic sequencer supporting up to 64 steps with various editing features
Comprehensive effects section including reverb, multi-effect with delays, modulation effects, and a dedicated overdrive
Performance controls on a full-sized, semi-weighted Fatar keyboard with various playing enhancements like polyphonic portamento and unison mode
Patch memory provides extensive storage and quick access options for user and factory presets

Specifications
Keybed: Premium, 3.5-octave, semi-weighted Fatar keyboard
Dimensions: 25″ L x 12.75″ W x 4.4″ H (63.5 cm x 32.4 cm x 11.2 cm)
Weight: 17 lbs. (7.7 kg)
